Mean indicator (closed)
Alexander.Gettinger · Tue Oct 12, 2010 1:32 am
Note: new version is available here: viewtopic.php?f=17&t=2526
viewtopic.php?f=27&t=2369&p=5104#p5104
The indicator was revised and updated
Re: Mean indicator
hpinvestment · Tue Oct 12, 2010 7:32 am
Hi Alexander
Can you please explain how this indicator works?
Re: Mean indicator
posurf · Wed Oct 13, 2010 2:35 am
Thanks
but is it possible to change the beginning of the time session, especially for the forex.
Re: Mean indicator
maurosg · Fri Oct 15, 2010 2:09 pm
Hi Alexander, thanks for the indicator
Thinking in Market profile, it is possible calculate this indicator whith “the mode” instead of “the mean”?
regards
Re: Mean indicator
virgilio · Mon Oct 18, 2010 3:13 pm
Is it possible to have a signal/strategy for this indicator? thank you.
Re: Mean indicator
Apprentice · Mon Oct 18, 2010 3:20 pm
Certainly, but you can specify, when, the conditions when the signal generated signals.
Re: Mean indicator
virgilio · Tue Oct 19, 2010 10:14 am
The goal is to have a strategy that generates buy/sell orders based on the same conditions as of the indicator.
Re: Mean indicator
Alexander.Gettinger · Wed Oct 20, 2010 12:43 am
Indicator updated. Added other time session for calculation MA.
Code: Select all `function Init() indicator:name(“Mean indicator”); indicator:description(“Mean indicator”); indicator:requiredSource(core.Tick); indicator:type(core.Indicator);
indicator.parameters:addGroup(“Calculation”); indicator.parameters:addString(“Mode”, “Mode”, “”, “Day”); indicator.parameters:addStringAlternative(“Mode”, “M1”, “”, “M1”); indicator.parameters:addStringAlternative(“Mode”, “M5”, “”, “M5”); indicator.parameters:addStringAlternative(“Mode”, “M15”, “”, “M15”); indicator.parameters:addStringAlternative(“Mode”, “H1”, “”, “H1”); indicator.parameters:addStringAlternative(“Mode”, “H2”, “”, “H2”); indicator.parameters:addStringAlternative(“Mode”, “H3”, “”, “H3”); indicator.parameters:addStringAlternative(“Mode”, “H4”, “”, “H4”); indicator.parameters:addStringAlternative(“Mode”, “H6”, “”, “H6”); indicator.parameters:addStringAlternative(“Mode”, “H8”, “”, “H8”); indicator.parameters:addStringAlternative(“Mode”, “Day”, “”, “Day”); indicator.parameters:addStringAlternative(“Mode”, “Month”, “”, “Month”);
indicator.parameters:addGroup(“Style”); indicator.parameters:addColor(“clrUP”, “UP Color”, “UP Color”, core.rgb(0, 255, 0)); indicator.parameters:addColor(“clrDN”, “DN Color”, “DN Color”, core.rgb(255, 0, 0)); indicator.parameters:addColor(“clrPrev”, “Prev Color”, “Prev Color”, core.rgb(0, 0, 255)); indicator.parameters:addInteger(“widthLinReg”, “Line width”, “Line width”, 1, 1, 5); indicator.parameters:addInteger(“styleLinReg”, “Line style”, “Line style”, core.LINE_SOLID); indicator.parameters:setFlag(“styleLinReg”, core.FLAG_LINE_STYLE); end
local first; local source = nil; local MeanUP=nil; local MeanDN=nil; local Buff=nil; local PrevBuff=nil; local Mode;
function Prepare() source = instance.source; Mode=instance.parameters.Mode; first = source:first()+2; Buff = instance:addInternalStream(first, 0); local name = profile:id() .. “(“ .. source:name() .. “, “ .. instance.parameters.Mode .. “)”; instance:name(name); MeanUP = instance:addStream(“MeanUP”, core.Line, name .. “.UP”, “UP”, instance.parameters.clrUP, first); MeanDN = instance:addStream(“MeanDN”, core.Line, name .. “.DN”, “DN”, instance.parameters.clrDN, first); PrevBuff = instance:createTextOutput (“Prev”, “Prev”, “Wingdings”, 10, core.H_Center, core.V_Center, instance.parameters.clrPrev, first); MeanUP:setWidth(instance.parameters.widthLinReg); MeanUP:setStyle(instance.parameters.styleLinReg); MeanDN:setWidth(instance.parameters.widthLinReg); MeanDN:setStyle(instance.parameters.styleLinReg); end
function Update(period, mode) if (period>first) then local d1,t1; d1,t1=source:date(period); local table1=core.dateToTable(d1); local CurD; if Mode==”M1” then CurD=table1.min; elseif Mode==”M5” then CurD=math.floor((table1.min)/5); elseif Mode==”M15” then CurD=math.floor((table1.min)/15); elseif Mode==”H1” then CurD=table1.hour; elseif Mode==”H2” then CurD=math.floor((table1.hour)/2); elseif Mode==”H3” then CurD=math.floor((table1.hour)/3); elseif Mode==”H4” then CurD=math.floor((table1.hour)/4); elseif Mode==”H6” then CurD=math.floor((table1.hour)/6); elseif Mode==”H8” then CurD=math.floor((table1.hour)/8); elseif Mode==”Day” then CurD=table1.day; elseif Mode==”Month” then CurD=table1.month; end local shift=period; local PrevD=CurD; while PrevD==CurD and shift>first do local d2,t2; d2,t2=source:date(shift); local table2=core.dateToTable(d2); if Mode==”M1” then PrevD=table2.min; elseif Mode==”M5” then PrevD=math.floor((table2.min)/5); elseif Mode==”M15” then PrevD=math.floor((table2.min)/15); elseif Mode==”H1” then PrevD=table2.hour; elseif Mode==”H2” then PrevD=math.floor((table2.hour)/2); elseif Mode==”H3” then PrevD=math.floor((table2.hour)/3); elseif Mode==”H4” then PrevD=math.floor((table2.hour)/4); elseif Mode==”H6” then PrevD=math.floor((table2.hour)/6); elseif Mode==”H8” then PrevD=math.floor((table2.hour)/8); elseif Mode==”Day” then PrevD=table2.day; elseif Mode==”Month” then PrevD=table2.month; end shift=shift-1; end shift=shift+1; if period>=shift+1 then Buff[period]=core.avg(source,core.range(shift+1,period)); if Buff[period]>Buff[period-1] then MeanUP[period]=Buff[period]; if Buff[period-1]<Buff[period-2] then MeanUP[period-1]=Buff[period-1]; end else MeanDN[period]=Buff[period]; if Buff[period-1]>Buff[period-2] then MeanDN[period-1]=Buff[period-1]; end end if period>shift then PrevBuff:set(period, Buff[shift], “\159”, “”); end end end end`
Re: Mean indicator (closed)
Apprentice · Mon Jan 30, 2017 7:03 am
Indicator was revised and updated.
Re: Mean indicator (closed)
Apprentice · Wed Jun 28, 2017 8:34 am
The strategy based on this indicator is available here. viewtopic.php?f=31&t=64850
