USDX Slope
Alexander.Gettinger · Wed Sep 29, 2010 10:59 pm
This indicator use 2 other indicators: Slope Direction Line (viewtopic.php?f=17&t=949) and USDX (viewtopic.php?f=17&t=609&p=1078).
If Slope Direction Line growing and USDX[period]-USDX[period-Shift]>0 then USDX_SLope UpUp and also
Slope Direction Line and USDX must be installed.
MQ4/MT4 version viewtopic.php?f=38&t=63997
The indicator was revised and updated
Re: USDX Slope
Alexander.Gettinger · Mon Oct 04, 2010 10:09 pm
Update indicator. Added other moving average methods and other prices for calculation.
Code: Select all `function Init() indicator:name(“USDX Slope indicator”); indicator:description(“USDX Slope indicator”); indicator:requiredSource(core.Bar); indicator:type(core.Oscillator); indicator.parameters:addGroup(“Calculation”); indicator.parameters:addInteger(“Shift”, “Shift”, “Shift”, 1); indicator.parameters:addInteger(“Period”, “Period”, “Period”, 80); indicator.parameters:addString(“Method”, “Method”, “”, “MVA”); indicator.parameters:addStringAlternative(“Method”, “MVA”, “”, “MVA”); indicator.parameters:addStringAlternative(“Method”, “EMA”, “”, “EMA”); indicator.parameters:addStringAlternative(“Method”, “KAMA”, “”, “KAMA”); indicator.parameters:addStringAlternative(“Method”, “LWMA”, “”, “LWMA”); indicator.parameters:addStringAlternative(“Method”, “TMA”, “”, “TMA”); indicator.parameters:addString(“Price”, “Price”, “”, “close”); indicator.parameters:addStringAlternative(“Price”, “open”, “”, “open”); indicator.parameters:addStringAlternative(“Price”, “close”, “”, “close”); indicator.parameters:addStringAlternative(“Price”, “high”, “”, “high”); indicator.parameters:addStringAlternative(“Price”, “low”, “”, “low”); indicator.parameters:addStringAlternative(“Price”, “median”, “”, “median”); indicator.parameters:addStringAlternative(“Price”, “typical”, “”, “typical”); indicator.parameters:addStringAlternative(“Price”, “weighted”, “”, “weighted”);
indicator.parameters:addGroup(“Style”); indicator.parameters:addColor(“clr1”, “Color UpUp”, “Color UpUp”, core.rgb(0, 255, 0)); indicator.parameters:addColor(“clr2”, “Color DnUp”, “Color DnUp”, core.rgb(255, 255, 0)); indicator.parameters:addColor(“clr3”, “Color UpDn”, “Color UpDn”, core.rgb(255, 0, 0)); indicator.parameters:addColor(“clr4”, “Color DnDn”, “Color DnDn”, core.rgb(255, 0, 255)); end
local first; local source = nil; local USDX; local Slope; local Shift; local buff1=nil; local buff2=nil; local buff3=nil; local buff4=nil;
function Prepare() source = instance.source; Shift=instance.parameters.Shift; USDX = core.indicators:create(“USDX”, source); if instance.parameters.Price==”open” then Slope = core.indicators:create(“SLOPE_DIRECTION_LINE”, source.open, instance.parameters.Period, instance.parameters.Method, instance.parameters.Price); elseif instance.parameters.Price==”close” then Slope = core.indicators:create(“SLOPE_DIRECTION_LINE”, source.close, instance.parameters.Period, instance.parameters.Method, instance.parameters.Price); elseif instance.parameters.Price==”high” then Slope = core.indicators:create(“SLOPE_DIRECTION_LINE”, source.high, instance.parameters.Period, instance.parameters.Method, instance.parameters.Price); elseif instance.parameters.Price==”low” then Slope = core.indicators:create(“SLOPE_DIRECTION_LINE”, source.low, instance.parameters.Period, instance.parameters.Method, instance.parameters.Price); elseif instance.parameters.Price==”median” then Slope = core.indicators:create(“SLOPE_DIRECTION_LINE”, source.median, instance.parameters.Period, instance.parameters.Method, instance.parameters.Price); elseif instance.parameters.Price==”typical” then Slope = core.indicators:create(“SLOPE_DIRECTION_LINE”, source.typical, instance.parameters.Period, instance.parameters.Method, instance.parameters.Price); else Slope = core.indicators:create(“SLOPE_DIRECTION_LINE”, source.weighted, instance.parameters.Period, instance.parameters.Method, instance.parameters.Price); end first = math.max(USDX.DATA:first(),Slope.DATA:first())+2; local name = profile:id() .. “(“ .. source:name() .. “)”; instance:name(name); buff1 = instance:addStream(“buff1”, core.Bar, name .. “UpUp”, “UpUp”, instance.parameters.clr1, first); buff2 = instance:addStream(“buff2”, core.Bar, name .. “DnUp”, “DnUp”, instance.parameters.clr2, first); buff3 = instance:addStream(“buff3”, core.Bar, name .. “UpDn”, “UpDn”, instance.parameters.clr3, first); buff4 = instance:addStream(“buff4”, core.Bar, name .. “DnDn”, “DnDn”, instance.parameters.clr4, first); end
function Update(period, mode) USDX:update(mode); Slope:update(mode); local i; if (period>first+Shift) then for i=first+Shift,period,1 do local USDX_Diff=USDX.DATA[i]-USDX.DATA[i-Shift]; if Slope.UpTrend[i]>0 then if USDX_Diff>0. then buff1[i]=100; buff2[i]=0; buff3[i]=0; buff4[i]=0; elseif USDX_Diff<0. then buff3[i]=100; buff1[i]=0; buff2[i]=0; buff4[i]=0; end elseif Slope.DnTrend[i]>0 then if USDX_Diff>0. then buff2[i]=100; buff1[i]=0; buff3[i]=0; buff4[i]=0; elseif USDX_Diff<0. then buff4[i]=100; buff1[i]=0; buff2[i]=0; buff3[i]=0; end end end end end`
Re: USDX Slope
Apprentice · Fri Jan 27, 2017 3:58 am
Indicator was revised and updated.
