NonLagDot signal
Source: https://fxcodebase.com/code/viewtopic.php?f=29&t=2072
Forum: 29 · Topic 2072 · 1 post(s)
NonLagDot signal
Alexander.Gettinger · Sun Sep 05, 2010 11:03 pm
Code: Select all `function Init() strategy:name(“NonLagDot signal”); strategy:description(“”);
strategy.parameters:addGroup(“Parameters”); strategy.parameters:addInteger(“Length”, “Length”, “Length”, 10); strategy.parameters:addInteger(“Filter”, “Filter”, “Filter”, 0); strategy.parameters:addDouble(“Deviation”, “Deviation”, “Deviation”, 0); strategy.parameters:addString(“TypeSignal”, “Type of signal”, “”, “direct”); strategy.parameters:addStringAlternative(“TypeSignal”, “direct”, “”, “direct”); strategy.parameters:addStringAlternative(“TypeSignal”, “reverse”, “”, “reverse”);
strategy.parameters:addString(“Period”, “Timeframe”, “”, “m5”); strategy.parameters:setFlag(“Period”, core.FLAG_PERIODS);
strategy.parameters:addGroup(“Signals”); strategy.parameters:addBoolean(“ShowAlert”, “Show Alert”, “”, true); strategy.parameters:addBoolean(“PlaySound”, “Play Sound”, “”, false); strategy.parameters:addFile(“SoundFile”, “Sound File”, “”, “”); end
local SoundFile; local gSourceBid = nil; local gSourceAsk = nil; local first; local Coeff; local Phase; local Len; local buff0=0; local trend0=0; local buff=0; local trend=0;
local BidFinished = false; local AskFinished = false; local LastBidCandle = nil;
function Prepare() local FastN, SlowN;
ShowAlert = instance.parameters.ShowAlert; if instance.parameters.PlaySound then SoundFile = instance.parameters.SoundFile; else SoundFile = nil; end assert(not(PlaySound) or (PlaySound and SoundFile ~= “”), “Sound file must be specified”); assert(instance.parameters.Period ~= “t1”, “Signal cannot be applied on ticks”);
ExtSetupSignal(“Rsi trend color signal:”, ShowAlert);
gSourceBid = core.host:execute(“getHistory”, 1, instance.bid:instrument(), instance.parameters.Period, 0, 0, true); gSourceAsk = core.host:execute(“getHistory”, 2, instance.bid:instrument(), instance.parameters.Period, 0, 0, false);
first = gSourceBid:first() + 2; Coeff=3.math.pi; Phase=instance.parameters.Length-1; Len=instance.parameters.Length4.+Phase;
local name = profile:id() .. “(“ .. instance.bid:instrument() .. “(“ .. instance.parameters.Length .. “)” .. instance.parameters.Filter .. “)” .. instance.parameters.Deviation .. “)”; instance:name(name); end
local LastDirection=nil;
– when tick source is updated function Update() if not(BidFinished) or not(AskFinished) then return ; end
local period;
– calculate enter logic if LastBidCandle == nil or LastBidCandle ~= gSourceBid:serial(gSourceBid:size() - 1) then LastBidCandle = gSourceBid:serial(gSourceBid:size() - 1);
period = gSourceBid:size() - 1; if period > first+Len+2 then local Weight=0; local Sum=0; local t=0; for i=0,Len-1,1 do local g=1./(Coefft+1.); if t<=0.5 then g=1.; end local beta=math.cos(math.pit); local alpha=gbeta; Sum=Sum+alphagSourceBid.close[period-i]; Weight=Weight+alpha; if t<1. then t=t+1./(Phase-1.); elseif t<Len-1. then t=t+7./(4.instance.parameters.Length-1.); end end buff0=buff; if Weight>0. then buff=(1.+instance.parameters.Deviation/100.)Sum/Weight; end if instance.parameters.Filter>0. then if math.abs(buff-buff0)<FiltergSourceBid:pipSize() then buff=buff0; end end trend0=trend; if buff-buff0>instance.parameters.FiltergSourceBid:pipSize() then trend=1; end if buff0-buff>instance.parameters.Filter*gSourceBid:pipSize() then trend=-1; end if ((trend0<trend and instance.parameters.TypeSignal==”direct”) or (trend0>trend and instance.parameters.TypeSignal==”reverse”)) and LastDirection~=1 then ExtSignal(gSourceAsk, period, “Buy”, SoundFile); LastDirection=1; end if ((trend0>trend and instance.parameters.TypeSignal==”direct”) or (trend0<trend and instance.parameters.TypeSignal==”reverse”)) and LastDirection~=-1 then ExtSignal(gSourceBid, period, “Sell”, SoundFile); LastDirection=-1; end end end end
function AsyncOperationFinished(cookie) if cookie == 1 then BidFinished = true; elseif cookie == 2 then AskFinished = true; end end
local gSignalBase = “”; – the base part of the signal message local gShowAlert = false; – the flag indicating whether the text alert must be shown
– Sets the base message for the signal – @param base The base message of the signals – ——————————————————— function ExtSetupSignal(base, showAlert) gSignalBase = base; gShowAlert = showAlert; return ; end
– Signals the message – @param message The rest of the message to be added to the signal – @param period The number of the period – @param sound The sound or nil to silent signal – ——————————————————— function ExtSignal(source, period, message, soundFile) if source:isBar() then source = source.close; end if gShowAlert then terminal:alertMessage(source:instrument(), source[period], gSignalBase .. message, source:date(period)); end if soundFile ~= nil then terminal:alertSound(soundFile, false); end end`
For work this signal must be installed NonLagDot indicator: viewtopic.php?f=17&t=1721
